Mouse NKp46/NCR1 Antibody

Bio-Techne includes R&D Systems | Catalog # AF2225

Catalog #
Size / Price

Key Product Details

Species Reactivity




Human, Rat


Agonist Activity, CyTOF-ready, Flow Cytometry, Immunohistochemistry, Western Blot



Antibody Source

Polyclonal Goat IgG

Product Summary for Mouse NKp46/NCR1 Antibody


Mouse myeloma cell line NS0-derived recombinant mouse NKp46/NCR1
Accession # Q8C567


Detects mouse NKp46/NCR1 in direct ELISAs and Western blots. In direct ELISAs, less than 15% cross-reactivity with recombinant human (rh) NKp46 is observed.







Scientific Data Images for Mouse NKp46/NCR1 Antibody

Mouse NKp46/NCR1 Antibody Induces IFN-? Secretion antibody in Activated Mouse NK Cells.

Mouse NKp46/NCR1 Antibody Induces IFN-gamma Secretion in Activated Mouse NK Cells.

Mouse NKp46/NCR1 Antigen Affinity-purified Polyclonal Antibody induces IFN-? secretion in mouse natural killer (NK) cells activated with 25 ng/mL Recombinant Mouse IL-2 (Catalog # 402-ML) and 25 ng/mL Recombinant Mouse IL-12 (Catalog # 419-ML), in a dose-dependent manner, as measured using the Quantikine Mouse IFN-? ELISA Kit (Catalog # MIF00). The ED50 for this effect is typically 0.4-2.4 µg/mL.
Detection of NKp46/NCR1 antibody in Mouse DX5/CD49b+Splenocytes antibody by Flow Cytometry.

Detection of NKp46/NCR1 in Mouse DX5/CD49b+Splenocytes by Flow Cytometry.

Mouse DX5/CD49b+splenocytes were stained with Goat Anti-Mouse NKp46/NCR1 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF2225, filled histogram) or control antibody (Catalog # AB-108-C, open histogram), followed by Allophycocyanin-conjugated Anti-Goat IgG Secondary Antibody (Catalog # F0108).
NKp46/NCR1 antibody in Mouse Spleen by Immunohistochemistry (IHC-Fr).

NKp46/NCR1 in Mouse Spleen.

NKp46/NCR1 was detected in perfusion fixed frozen sections of mouse spleen using Goat Anti-Mouse NKp46/NCR1 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF2225) at 3 µg/mL for 1 hour at room temperature followed by incubation with the Anti-Goat IgG VisUCyte™ HRP Polymer Antibody (Catalog # VC004). Tissue was stained using DAB (brown) and counterstained with hematoxylin (blue). Specific staining was localized to cytoplasm in lymphocytes. View our protocol for IHC Staining with VisUCyte HRP Polymer Detection Reagents.

Applications for Mouse NKp46/NCR1 Antibody

Recommended Usage

Agonist Activity

0.4-2.4 µg/mL
Sample: Mouse natural killer (NK) cells activated with Recombinant Mouse IL-2 (Catalog # 402-ML) and Recombinant Mouse IL-12 (Catalog # 419-ML)


Ready to be labeled using established conjugation methods. No BSA or other carrier proteins that could interfere with conjugation.

Flow Cytometry

2.5 µg/106 cells
Sample: Mouse DX5/CD49b+ splenocytes


3-15 µg/mL
Sample: Perfusion fixed frozen sections of mouse spleen

Western Blot

0.1 µg/mL
Sample: Recombinant Mouse NKp46/NCR1 Fc Chimera (Catalog # 2225-NK)
Please Note: Optimal dilutions of this antibody should be experimentally determined.

Reviewed Applications

Read 2 reviews rated 5 using AF2225 in the following applications:

Published Applications

Read 62 publications using AF2225 in the following applications:

Formulation, Preparation, and Storage


Antigen Affinity-purified

Endotoxin Level

<0.10 EU per 1 μg of the antibody by the LAL method.


Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.

Reconstitution Buffer Available:
Size / Price


Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.


The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below. *Small pack size (SP) is shipped with polar packs. Upon receipt, store it immediately at -20 to -70 °C

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: NKp46/NCR1

NKp46, along with NKp30 and NKp44, are activating receptors that have been collectively termed the natural cytotoxicity receptors (NCR) (1). These receptors are expressed almost exclusively by NK cells and play a major role in triggering some of the key lytic activities of NK cells. In human systems, the CD56dimCD16+ subpopulation that makes up the majority of NK cells in the peripheral blood and spleen expresses NKp46 in both resting and activated states (2). The main NK cell population of the lymph node (CD56brightCD16-) expresses low levels of NKp46 in resting cells, but expression is upregulated by IL-2. Mouse NKp46, also known as MAR-1 (3), is a type I transmembrane protein with two extracellular Ig-like domains. It has a positive charge in its transmembrane domain that permits association with the ITAM-bearing signal adapter proteins, CD3 zeta and Fc epsilon RI gamma (4). Studies with neutralizing antibodies indicate that the three NCR are primarily responsible for triggering the NK-mediated lysis of many human tumor cell lines. Blocking any of the NCRs individually resulted in partial inhibition of tumor cell lysis, but nearly complete inhibition of lysis was observed if all three receptors were blocked simultaneously (5). NKp46 has also been implicated in recognition of virus-infected cells through its capacity to bind to viral hemagglutinins (6-8).


  1. Moretta, L. and A. Moretta (2004) EMBO J. 23:255.
  2. Ferlazzo, G. et al. (2004) J. Immunol. 172:1455.
  3. Biassoni, R. et al. (1999) Eur. J. Immunol. 29:1014.
  4. Westgaard, I. et al. (2004) J. Leukoc. Biol. PMID 15356098.
  5. Pende, D. et al. (1999) J. Exp. Med. 190:1505.
  6. Arnon, T. et al. (2004) Blood 103:664.
  7. Arnon, T. et al. (2001) Eur. J. Immunol. 31:2680.
  8. Mandelboim, O. et al. (2001) Nature 409:1055.

Alternate Names

CD335, Ly94, MAR-1, NCR1

Entrez Gene IDs

9437 (Human); 17086 (Mouse); 100141419 (Porcine); 102115479 (Cynomolgus Monkey)

Gene Symbol



Additional NKp46/NCR1 Products

Product Documents for Mouse NKp46/NCR1 Antibody

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot number in the search box below.

Note: Certificate of Analysis not available for kit components.

Product Specific Notices for Mouse NKp46/NCR1 Antibody

For research use only
