Key Product Details
| Description: | Orange fluorescent mitochondrial stain for live cells, Δψm dependent |
| Purity: | ≥95% (HPLC) |
| Molecular Weight: | 416.95 |
Customers also Viewed
Biological Activity for MitoBrilliant™ Live 549
MitoBrilliant probes have been developed to overcome some common limitations encountered with standard mitochondrial trackers, offering clearer answers to scientific questions. They are next-generation fluorescent stains for the localization and tracking of mitochondria in both live and fixed cells. The range harnesses Janelia Fluor® dye technology, conferring some of the properties that make these widely used dyes, into mitochondrial stains.
The MitoBrilliant™ Live dyes accumulate in the mitochondria of live cells in a mitochondrial membrane potential (Δψm) dependent manner. Upon loss of the mitochondrial membrane potential, the dyes disperse, and so provide a dynamic assessment of the mitochondrial membrane potential in live cells. Two dyes are available: MitoBrilliant™ Live 646 (red emission) and MitoBrilliant™ Live 549 (yellow/orange emission).
A universal stain for mitochondria in both live and fixed cells is also available: MitoBrilliant™ 646.
Please refer to the protocol for guidelines on product use, and download the MitoBrilliant Product Guide to view data for each of the dyes in different applications.
MitoBrilliant is a trademark of Bio-Techne Corp.
| Product Name | Core dye structure | Abs/Em (nm) | Δψm dependent | Live/Fixed cell use | Stain pre-fixed cells? | Image without wash step | Demonstrated Applications | MitoBrilliant™ 646 Cat. No. 7700 | Janelia Fluor® technology | 655/668 | No* | Suitable for both live and fixed cell work | Yes | Yes, but replacing media recommended | Fixed-cell imaging, Live-cell imaging, Flow Cytometry, IHC/ICC, Super-resolution microscopy – STED, High-content screening |
|---|---|---|---|---|---|---|---|
| MitoBrilliant™ Live 646 Cat. No. 7417 | Janelia Fluor® technology | 648/662 | Yes | Live-cell work only | No | Yes, but replacing media recommended | Live-cell imaging, Flow Cytometry, High-content screening |
| MitoBrilliant™ Live 549 Cat. No. 7693 | Janelia Fluor® technology | 550/568 | Yes | Live-cell work only | No | Yes, but replacing media recommended | Live-cell imaging, Flow Cytometry, High-content screening |
Optical Data for MitoBrilliant™ Live 549
| Emission Color | Yellow/Orange |
|---|---|
| λabs | 550 nm |
| λem | 568 nm |
| Extinction Coefficient (ε) | 100000 M-1cm-1 |
| Closest Laser line | 561 nm |
|
Live-cell image of mitochondria stained with MitoBrilliant™ Live 549 HeLa cells were incubated with MitoBrilliant™ Live 549 (100 nM) for 40 minutes and counterstained with DAPI (Catalog # 5748). Image was taken using an LSM880 Confocal using a 63x objective. Scale bar = 10 µm. |
Plan Your Experiments
Use our spectra viewer to interactively plan your experiments, assessing multiplexing options. View the excitation and emission spectra for our fluorescent dye range and other commonly used dyes.
Spectra Viewer
Citations for MitoBrilliant™ Live 549
Please visit our Instrument Citation Database to search our collection of scientific articles that feature our instruments.
