Human TRA-1-60(R) Neuraminidase Resistant Epitope Antibody
R&D Systems, part of Bio-Techne | Catalog # MAB4770
Scientific images may be resized, cropped, or adjusted for brightness or contrast for presentation purposes. These updates are limited to presentation and do not affect the underlying scientific interpretation of the data. Where available, additional source data may be provided upon request.
Conjugate
Catalog #
Key Product Details
Species Reactivity
Validated:
Human
Cited:
Human, Canine
Applications
Validated:
Flow Cytometry, Immunocytochemistry, CyTOF-reported
Cited:
Immunohistochemistry, Western Blot, Flow Cytometry, Immunocytochemistry, Labeling
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgM Clone # TRA-1-60
Product Specifications
Immunogen
2102Ep human embryonal carcinoma cell line
Specificity
Detects human TRA‑1‑60(R).
Clonality
Monoclonal
Host
Mouse
Isotype
IgM
Scientific Data Images for Human TRA-1-60(R) Neuraminidase Resistant Epitope Antibody
Detection of TRA‑1‑60 in BG01V Human Cells by Flow Cytometry
BG01V human embryonic stem cells were stained with Mouse Anti-Human TRA-1-60 Neuraminidase Resistant Epitope Monoclonal Antibody (Catalog # MAB4770, filled histogram) or isotype control antibody followed by Phycoerythrin-conjugated Anti-Mouse IgM Secondary Antibody (F0116).
TRA‑1‑60 in BG01V Human Stem Cells.
TRA-1-60 was detected in immersion fixed BG01V human embryonic stem cells using Mouse Anti-Human TRA-1-60 Neuraminidase Resistant Epitope Monoclonal Antibody (Catalog # MAB4770) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Mouse IgM Secondary Antibody (yellow; NL019) and counterstained with DAPI (blue). View our protocol for Fluorescent ICC Staining of Cells on Coverslips.
TRA‑1‑60(R) in ADLF1 and FAB2 Stem Cell Lines.
TRA-1-60(R) was detected in immersion fixed ADLF1 (top panel) and FAB2 (bottom panel) induced pluripotent stem cell lines using Mouse Anti-Human TRA-1-60(R) Neuraminidase Resistant Epitope Monoclonal Antibody (Catalog # MAB4770) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Mouse IgG Secondary Antibody (red; NL007) and counterstained with DAPI (blue). Specific staining was localized to cell surfaces. View our protocol for Fluorescent ICC Staining of Stem Cells on Coverslips.
Applications for Human TRA-1-60(R) Neuraminidase Resistant Epitope Antibody
Application
Recommended Usage
CyTOF-reported
This clone has been commercially reported for use in CyTOF®. Ready to be labeled using established conjugation methods. No BSA or other carrier proteins that could interfere with conjugation.
Flow Cytometry
0.25 µg/106 cells
Sample: BG01V human embryonic stem cells and iPSC cells
Sample: BG01V human embryonic stem cells and iPSC cells
Immunocytochemistry
8-25 µg/mL
Sample: Immersion-fixed BG01V human embryonic stem cells immersion fixed ADLF1 and FAB2 induced pluripotent stem cell lines
Sample: Immersion-fixed BG01V human embryonic stem cells immersion fixed ADLF1 and FAB2 induced pluripotent stem cell lines
Reviewed Applications
Read 1 review rated 5 using MAB4770 in the following applications:
Formulation, Preparation, and Storage
Purification
IgM-specific Affinity-purified from hybridoma culture supernatant
Reconstitution
Reconstitute at 0.5 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.
Shipping
Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Background: TRA-1-60(R)
TRA-1-60 is a monoclonal antibody raised against a cell surface antigen of human embryonal carcinoma (EC) cells (1). The TRA-1-60 epitope is also found on human embryonic stem (ES) cells and primordial germ cells, and TRA-1-60 serves as a serum marker in patients with germ cell tumors (2‑4). Investigation into the identity of the TRA-1-60 epitope demonstrated that it is a carbohydrate carried by a cell surface, sialylated, keratan sulfate proteoglycan (5). Subsequent evidence implicated podocalyxin as a carrier for the TRA-1-60 epitope (6).
References
- Andrews, P. et al. (1984) Hybridoma 3:347.
- Thomson, J. et al. (1998) Science 282:1145.
- Giwercman, A. et al. (1993) Cancer 72:1308.
- Marrink, J. et al. (1991) Int. J. Cancer 49:368.
- Badcock, G. et al. (1999) Cancer Res. 59:4715.
- Schopperle, W. and W. DeWolf (2007) Stem Cells 25:723.
Long Name
Tumor-related Antigen-1-60 [R]
Alternate Names
TRA160(R)
Entrez Gene IDs
5420 (Human)
Gene Symbol
PODXL
Additional TRA-1-60(R) Products
Product Documents for Human TRA-1-60(R) Neuraminidase Resistant Epitope Antibody
Product Specific Notices for Human TRA-1-60(R) Neuraminidase Resistant Epitope Antibody
For research use only
