Key Product Details

Species Reactivity

HCoV-HKU1

Applications

Immunocytochemistry

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG2A Clone # 1045307

View all Spike RBD Antibodies »

Product Specifications

Immunogen

Human embryonic kidney cell HEK293-derived HCoV-HKU1 Spike RBD
Thr310-Tyr624
Accession # Q5MQD0.1

Specificity

Detects Human Coronavirus HCoV-HKU1 Spike RBD and 229E in direct ELISAs. No staining of NL63 HKu1.

Clonality

Monoclonal

Host

Mouse

Isotype

IgG2A

Scientific Data Images for HCoV-HKU1 Human Coronavirus Spike RBD Antibody

Spike RBD in CHO Chinese hamster ovary cell line transfected with HCoV-HKU1.

Spike RBD was detected in immersion fixed CHO Chinese hamster ovary cell line transfected with HCoV-HKU1 (positive staining), HCoV-229E transfected (negative staining), HCoV-NL63 transfected cell (negative staining), and CHO Chinese hamster ovary cell line (non-transfected, negative staining) using Mouse Anti-HCoV-HKU1 Spike RBD Monoclonal Antibody (Catalog # MAB10936) at 8 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Mouse IgG Secondary Antibody (red; NL007) and counterstained with DAPI (blue). Specific staining was localized to cell cytoplasm. Staining was performed using our protocol for Fluorescent ICC Staining of Non-adherent Cells.

Applications for HCoV-HKU1 Human Coronavirus Spike RBD Antibody

Application
Recommended Usage

Immunocytochemistry

8-25 µg/mL
Sample: Immersion fixed CHO Chinese hamster ovary cell line transfected with HCoV-HKU1

Formulation, Preparation, and Storage

Purification

Protein A or G purified from hybridoma culture supernatant

Reconstitution

Reconstitute at 0.5 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.

Reconstitution Buffer Available:
Size / Price
Qty

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Shipping

Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: Spike RBD

HCoV-HKU1 was identified in Hong Kong in 2005 as a new human coronavirus (1). Coronaviruses are a family of viruses that are commonly comprised of a large plus-strand RNA genome and four structural proteins: Spike protein (S), Envelope protein (E), Membrane protein (M), and Nucleocapsid protein(N). There are two well-known human coronavirus families that infect humans: Alpha coronaviruses which includes HCoV-229E and HCoV-NL63; beta coronaviruses that includes HCov-OC43, Severe Acute Respiratory Syndrome (SARS-CoV), Middle East Respirator Syndrome (MERS-CoV), and global pandemic Covid-19 (SARS-CoV2) (2). The HCoV-HKU1 Spike Protein (S Protein) is a glycoprotein that mediates membrane fusion and viral entry. As with most coronaviruses, proteolytic cleavage of the S protein generates two distinct peptides, S1 and S2 subunits. The S1 subunit is focused on attachment of the protein to the host receptor, while the S2 subunit is involved with cell fusion. The receptor binding domain (RBD) of HCoV-HKU1 is located at C-terminal region of S1 subunit, similar to SARS-COV, MERS-COV and SARS-COV2, but the RBD regions do not share significant amino acid sequence identity (3). HCoV-HKU1 has been demonstrated to bind specifically to 9-O-acetylated sialic acids (9-O-Ac-Sias) attached as terminal residues to glycan chains on glycoproteins and lipids, but additional receptors remain unknown (4). HCoV-HKU1, along with HCov-OC43, differ from other cornonaviruses in that their virions possess two types of surface projections, both involved in attachment: large "spikes" that are comprised of homotrimers of the S protein, and unique, smaller protrusions, comprised of the homodimeric hemagglutinin-esterase (HE) (5).

References

  1. Woo, P. et al. (2005) J. Virol.79:884.
  2. Ogimi, C. et al. (2020) J Pediatric Infect Dis Soc doi: 10.1093/jpids/piaa037.
  3. Qian, Z. et al. (2015) J. Virol. 89:8816.
  4. Huang, X. et al. (2015) J Virol 89:7202.
  5. Hulswit, R.J.G. et al. (2019) PNAS 116:2681.

Long Name

Spike Receptor Binding Domain

Entrez Gene IDs

3200426 (HCoV-HKU1); 14254594 (MERS-CoV); 1489668 (SARS-CoV); 43740568 (SARS-CoV-2)

Gene Symbol

S

UniProt

Q5MQD0.1

Additional Spike RBD Products

Product Documents for HCoV-HKU1 Human Coronavirus Spike RBD Antibody

Product Datasheets

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot number in the search box below.

Note: Certificate of Analysis not available for kit components.

Download SDS

Product Specific Notices for HCoV-HKU1 Human Coronavirus Spike RBD Antibody

For research use only
