Human 2B4/CD244/SLAMF4 - Ready-To-Use ELISA Kit (Colorimetric)

Name: Human 2B4/CD244/SLAMF4 - Ready-To-Use ELISA Kit (Colorimetric)
Brand: Novus Biologicals
SKU: NBP3-54482

Novus Biologicals, part of Bio-Techne | Catalog # NBP3-54482

Submit a review

Product Datasheet / COA

100% Guarantee

Product Specifications
Precision
Kit Contents
Preparation & Storage
Background
Product Documents
Specific Notices

Key Product Details

Sample Type & Volume Required Per Well

Tissue homogenates, cell lysates and other biological fluids (100 uL)

Sensitivity

0.067 ng/mL (example only; lot dependent)

Assay Range

0.156 - 10 ng/mL (example only; lot dependent)

View all 2B4/CD244/SLAMF4 ELISA Kits »

Product Specifications

Assay Type

Sandwich ELISA

Kit Type

ELISA Kit (Colorimetric)

Reactivity

Human

Description

The Ready-To-Use ELISA kit offers pre-diluted detection reagents and a shorter experimental time.
Assay Length: 3 hours

Precision

Intra-Assay Precision (Precision within an assay) %CV < 10 (example only; lot dependent)

Inter-Assay Precision (Precision between assays) %CV < 12 (example only; lot dependent)

Kit Contents for Human 2B4/CD244/SLAMF4 - Ready-To-Use ELISA Kit (Colorimetric)

Pre-coated 96T strip plate, Plate sealer for 96 wells, Standard, Standard Diluent, Detection Solution A, Detection Solution B, TMB Substrate, Stop Solution, Wash Buffer (30 x concentrate), Instruction manual

Preparation and Storage

Stability & Storage

Storage of components varies. See protocol for specific instructions.

Background: 2B4/CD244/SLAMF4

2B4, also known as CD244 and SLAMF4, is a type I transmembrane glycoprotein that is member of the signaling lymphocyte activation molecule (SLAM) subfamily in immunoglobulin (Ig) superfamily (1,2). The 2B4 protein plays a role in immune system associated diseases including the recognition and clearance of cancer cells, infected cells, and key allergy cells (1). 2B4 is expressed as a heterophilic receptor on the cell membrane of natural killer (NK) cells in addition to on monocytes and basophils, gamma/delta T cells, a subset of CD8+ T cells, and other immune cells and tissues (1). Additionally, 2B4 is considered a marker for CD8+ T cell exhaustion in chronic infection and increased expression has been observed in diseases including lymphocytic choriomeningitis virus (LCMV) and hepatitis B virus (HBV) (2). Human 2B4 protein is 370 amino acids (aa) in length with a theoretical molecular weight (MW) of 41 kDa (3). However, 2B4 contains multiple glycosylation sites that increases its observed MW to ~70 kDa (3). The 2B4/CD244 protein consists of a 21 aa signal peptide followed by an extracellular domain (ECD) with two Ig-like domains, a single transmembrane domain, and four cytoplasmic immunoreceptor tyrosine-based switch motifs (ITSMs) (3).

The 2B4 receptor has both activating and inhibitory signaling properties (1,4). 2B4's ligand is CD48, which is expressed on hematopoietic cells (4, 5). When bound to CD48, subsequent phosphorylation of the ITSMs occurs, followed by recruitment of SH-2-containing adaptor protein (SAP) and Fyn, leading to phosphorylation of PLCgamma and Vav1, and resulting in NK cell activation (4). In the absence of SAP, Src homology region 2-containing protein tyrosine phosphatases (SHP) get recruited and inhibits NK cell activation (4). In the context of infection such as Epstein-Barr virus (EBV), when lacking SAP, 2B4 has been shown to have an inhibitory function via impaired T cell cytotoxicity against EBV-infected cells (6). While 2B4 has a role in eliciting CD8+ T cell response, overexpression of 2B4 can lead to T cell exhaustion in states of chronic infection (6). Studies have suggested that the antibody blockade of the 2B4-CD48 interaction might enhance T cell and NK cell function, however given both the activating and inhibitory properties of the 2B4 receptor, more research needs to be done to prevent unwanted effects (6).

References

1. Buller CW, Mathew PA, Mathew SO. Roles of NK Cell Receptors 2B4 (CD244), CS1 (CD319), and LLT1 (CLEC2D) in Cancer. Cancers (Basel). 2020 Jul 1;12(7):1755. https://doi.org/10.3390/cancers12071755

2. Catakovic K, Klieser E, Neureiter D, Geisberger R. T cell exhaustion: from pathophysiological basics to tumor immunotherapy. Cell Commun Signal. 2017;15(1):1. https://doi.org/10.1186/s12964-016-0160-z

3. Uniprot (Q9BZW8)

4. Chen Y, Lu D, Churov A, Fu R. Research Progress on NK Cell Receptors and Their Signaling Pathways. Mediators Inflamm. 2020 Jul 24;2020:6437057. https://doi.org/10.1155/2020/6437057.

5. Pahima H, Puzzovio PG, Levi-Schaffer F. 2B4 and CD48: A powerful couple of the immune system. Clin Immunol. 2019 Jul;204:64-68. https://doi.org/10.1016/j.clim.2018.10.014.

6. Waggoner SN, Kumar V. Evolving role of 2B4/CD244 in T and NK cell responses during virus infection. Front Immunol. 2012;3:377. https://doi.org/10.3389/fimmu.2012.00377

Alternate Names

CD244, NAIL, NKR2B4, Nmrk, SLAMF4

Gene Symbol

CD244

Additional 2B4/CD244/SLAMF4 Products

Product Documents for Human 2B4/CD244/SLAMF4 - Ready-To-Use ELISA Kit (Colorimetric)

Product Datasheets

Download Product Datasheets

COA

Product Specific Notices for Human 2B4/CD244/SLAMF4 - Ready-To-Use ELISA Kit (Colorimetric)

This product is for research use only and is not approved for use in humans or in clinical diagnosis. ELISA Kits are guaranteed for 6 months from date of receipt.
