Product Overview
The RNAscope Multiomic LS Assay enables highly sensitive and specific detection of both RNA and proteins in the same tissue section for a true multiomic spatial assay. Proven class-leading single-molecule RNAscope technology is leveraged to enable simultaneous detection of up to 6 total proteins and RNA targets with single cell resolution.
This assay is based on the same technology as the RNAscope Multiplex v2 assay and is compatible with your existing probes and workflows. With both protease and a new completely protease-free workflow, the kit provides significantly upgraded capabilities and benefits.
The RNAscope Multiomic LS Assay is designed as an automated assay for the BOND RX™ and RXm by Leica Biosystems.
Image (right): Human cervical cancer tissue. Proteins detected: CD4 (yellow), CD8 (white), PanCK (pink), & FoxP3 (green). RNAs detected: GZMB (orange) & IFNG (red).
Choose Your Protease-Free Multiomic Workflow
Choose Your Protease-Free Multiomic Workflow
- Protease-free preserves antigen integrity for wide antibody compatibility and maintenance of tissue morphology.
Use a sequential co-detection workflow by performing RNAscope detection and following with your usual IHC.
Or
- Use the full RNAscope Multiomic workflow for more protein plex and minimal optimization by selecting from a pre-qualified RNAscope antibodies.
Note: Kit also includes protease to support your ongoing projects.
Fast and Flexible Assay Design
Fast and Flexible Assay Design
- Up to 6 total plex.
- RNAscope probes let you detect any RNA transcripts. Any gene. Any species.
- Accelerate multiomic assay design at higher plex by selecting from RNAscope antibodies. Pre-qualified RNAscope primary and secondary antibodies minimize optimization time.
Gold-Standard RNAscope Detection
Gold-Standard RNAscope Detection
- Proven performance for FFPE samples and high to low expressing target genes.
- Backed by over 14K publications in peer-reviewed journals.
- Over 80K probes visualized.
- Compatible with downstream H&E staining.
Tumor-Associated Macrophages Visualized Using the Multiomic LS Assay
- Assess cytokine profiles and identify their cellular source.
- Visualize gene signatures with cell-specific markers to assess activation states of immune cells.
Image: Human breast cancer tissue stained for 2 protein targets (CD68 and CD163) and 4 RNA targets (IL10, IL-1B, TNFα, and CXCL10).
Protease-Free Workflow Flexibility
RNA Only
- Unparalleled sensitivity and specificity.
- Detect up to 6 RNA targets at the same time.
- Kit includes both protease-free and protease for maximum compatibility.
Sequential Co-Detection
- If you already have an in-place IHC solution, perform RNA and protein detection sequentially.
- Perform RNAscope detection with protease-free reagents to preserve antigen integrity, then follow with standard IHC or IF detection using your own antibodies.
Full Multiomic Workflow
- For increased protein plex, select from RNAscope primary and antibodies for a total of 6 RNA and protein targets.
- Pre-qualified RNAscope antibodies reduce optimization time and effort.
Expansion Capabilities for an Advanced Multiomic Assay
RNAscope Probes
RNAscope Probes
RNAscope in any species, any tissue
- Single-molecule sensitivity and specificity
- Select from a catalog of pre-designed RNAscope probes or design a custom probe
BaseScope Expansion Pack
BaseScope Expansion Pack
Sequence-specific variant discrimination
- See exon junctions or differentiate between splice variants
- Detect cells transduced in gene therapy, gene editing products, microexons
ProximityScope
ProximityScope
Visualize Functional Protein Interactions
- Detect cell-cell interactions, receptor dimerization, or intracellular protein interactions
- Gain insights into health and disease, stratify patients, or optimize therapeutic development
RNAscope Antibodies
RNAscope Antibodies
Expanded RNA-protein multiomics
- Pre-qualified RNAscope primaries to minimize optimization time
- RNAscope secondaries for use with your own rabbit- and mouse-hosted primary antibodies
RNAscope Channel Compatibility | ||||||
| C1/B1 | C2/B2 | C3 | C4 | C5 | C6 | |
| RNAscope Probes | RNAscope C1 Probe | RNAscope C2 Probe | RNAscope C3 Probe | RNAscope C4 Probe | RNAscope C5 Probe | RNAscope C6 Probe |
| BaseScope Probes | BaseScope B1 Probe | BaseScope B2 Probe | ||||
| RNAscope Antibodies | RNAscope anti-rabbit C1* | RNAscope anti-mouse C2* | RNAscope primary antibody C3 | RNAscope primary antibody C4 | RNAscope primary antibody C5 | RNAscope primary antibody C6 |
| ProximityScope Antibodies | ProximityScope antibody pair | |||||
*To be used with user-provided rabbit/mouse primary antibody
Immunology and Inflammation
Immunology and Inflammation
- Assess cytokine profiles and identify their cellular source
- Visualize gene signatures with cell-specific markers to assess activation states of immune cell
Fluorophore Selection
The RNAscope Multiomic LS assay supports detection of up to 6 targets simultaneously. The following are the recommended ClariTSA™ fluorophores to maximize sensitivity and minimize spectral overlap. If using other TSA fluorophores, select the best combination for your imaging system.
Bio-Techne TSA Fluorophore Kits | Catalog # | 3-plex |
|---|---|---|
| ClariTSA Fluorophore Kit 520 | 323271 | ✔ |
| ClariTSA Fluorophore Kit 570 | 323272 | ✔ |
| ClariTSA Fluorophore Kit 650 | 323273 | ✔ |
Opal TSA Fluorophores | Quanterix Catalog # | 3-plex | 4-plex | 5- or 6-plex |
|---|---|---|---|---|
| Opal 480 Reagent Pack | FP1500001KT | ✔ | ||
| Opal 520 Reagent Pack | FP1487001KT | ✔ | ✔ | ✔ |
| Opal 570 Reagent Pack | FP1488001KT | ✔ | ✔ | ✔ |
| Opal 620 Reagent Pack | FP1495001KT | ✔ | ||
| Opal 690 Reagent Pack | FP1497001K | ✔ | ✔ | ✔ |
| Opal Polaris 780 Reagent Pack Antibody Diluent/Block (needed when using Opal Polaris 780) | ARO1001EA | ✔ | ✔ |
NOTE: For 5-plex assay, select any 5 of the recommended fluorophores.
RNAscope Multiomic LS Reagent Kits
Assay Components | Catalog # | Number of Assays |
|---|---|---|
| RNAscope Multiomic CORE & C1 - C3 Channel Kit | 60 20 | |
| RNAscope Multiomic CORE & C1 - C6 Channel Kit | 60 20 | |
| RNAscope Multiomic C4 Channel Reagents | 60 20 | |
| RNAscope Multiomic C5 Channel Reagents | 60 20 | |
| RNAscope Multiomic C6 Channel Reagents | 60 20 |
Human TIL Panel Primary Antibodies | Catalog # | Number of Assays |
|---|---|---|
| RNAscope Ab Hs CD4-C3 | 322949 | 20 |
| RNAscope Ab Hs-CD8-C4 | 322951 | 20 |
| RNAscope Ab-Hs-PanCK-C5 | 322952 | 20 |
| RNAscope Ab-Hs FoxP3-C6 | 322953 | 20 |
RNAscope Multiomic Human TIL Antibody Panel Pack includes CD4, CD8, PanCK and FoxP3 antibodies | 323185 | 20 |
Neuro Panel Primary AntibodiesCross reacts against mouse, human, and non-human primate targets. | Catalog # | Number of Assays |
|---|---|---|
| RNAscope Ab NeuN-C3 | AB0014-C3 | 20 |
| RNAscope Ab GFAP-C4 | AB0024-C4 | 20 |
| RNAscope Ab IBA-1-C5 | AB0034-C5 | 20 |
RNAscope Multiomic Neuronal Antibody Panel Pack includes NeuN, GFAP and IBA-1 antibodies | 321780 | 20 |
RNAscope Secondary Antibodies | Catalog # | Number of Assays |
|---|---|---|
| RNAscope anti-rabbit-C1 | 322954 | 60 |
| RNAscope anti-mouse-C2 | 322956 | 60 |
Control Probes | Catalog # | Number of Assays |
|---|---|---|
RNAscope Multiomic LS 6-plex Positive Control Probe-Hs (RTU mixture of 6 probes targeting human housekeeping genes in each of 6 separate channels: Hs-POLR2A-C1, Hs-PPIB-C2, Hs-UBC-C3, Hs-HPRT1-C4, Hs-ACTB-C5, Hs-TUBB-C6.) | 323198 | 30 |
| Hs-Polr2A | 310458 | 30 |
| Hs-PPIB-C2 | 313908-C2 | 30 |
| Hs-UBC-C3 | 312028-C3 | 30 |
| Hs-HPRT1-C4 | 310348-C4 | 30 |
| Hs-ACTB-C5 | 310148-C5 | 30 |
| Hs-TUBB-C6 | 588798-C6 | 30 |
| RNAscope Multiomic LS 6-plex Negative Control Probe | 323208 | 30 |
| RNAscope Multiomic LS 6-plex Positive Control Probe-Mn (RTU mixture of 6 probes targeting mouse housekeeping genes in each of 6 separate channels. Mm-POLR2A-C1, Mm-PPIB-C2, Mm-UBC-C3, Mm-HPRT1-C4, Mm-ACTB-C5, Mm-Sdha-C6) | 323988 | 30 |
RNAscope Multiomic LS Assay Brochure
RNAscope Antibodies for the RNAscope Multiomic LS Assay
Please Note: For ordering checklists and user manual please see the documents section on each individual product page to download.
