Mouse CCL19/MIP-3 beta Antibody
R&D Systems, part of Bio-Techne | Catalog # AF880
Scientific images may be resized, cropped, or adjusted for brightness or contrast for presentation purposes. These updates are limited to presentation and do not affect the underlying scientific interpretation of the data. Where available, additional source data may be provided upon request.
Conjugate
Catalog #
Key Product Details
Species Reactivity
Validated:
Mouse
Cited:
Human, Mouse, Transgenic Mouse
Applications
Validated:
Western Blot, Neutralization, Immunocytochemistry
Cited:
Immunohistochemistry, Immunohistochemistry-Paraffin, Immunohistochemistry-Frozen, Neutralization, Flow Cytometry
Label
Unconjugated
Antibody Source
Polyclonal Goat IgG
Product Specifications
Immunogen
E. coli-derived recombinant mouse CCL19/MIP-3 beta
Gly26-Val107 (Ser108LeuGlu)
Accession # Q548P0
Gly26-Val107 (Ser108LeuGlu)
Accession # Q548P0
Specificity
Detects mouse CCL19/MIP-3 beta in direct ELISAs and Western blots.
Clonality
Polyclonal
Host
Goat
Isotype
IgG
Endotoxin Level
<0.10 EU per 1 μg of the antibody by the LAL method.
Scientific Data Images for Mouse CCL19/MIP-3 beta Antibody
Chemotaxis Induced by CCL19/MIP-3 beta and Neutralization by Mouse CCL19/MIP-3 beta Antibody.
Recombinant Mouse CCL19/MIP-3 beta (Catalog # 440-M3) chemoattracts the BaF3 mouse pro-B cell line transfected with human CCR7 in a dose-dependent manner (orange line). The amount of cells that migrated through to the lower chemotaxis chamber was measured by Resazurin (Catalog # AR002). Chemotaxis elicited by Recombinant Mouse CCL19/MIP-3 beta (50 ng/mL) is neutralized (green line) by increasing concentrations of Goat Anti-Mouse CCL19/MIP-3 beta Antigen Affinity-purified Polyclonal Antibody (Catalog # AF880). The ND50 is typically 0.8-4 µg/mL.
CCL19/MIP‑3 beta in Mouse Splenocytes.
CCL19/MIP-3 beta was detected in immersion fixed mouse splenocytes using Goat Anti-Mouse CCL19/MIP-3 beta Antigen Affinity-purified Polyclonal Antibody (Catalog # AF880) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Goat IgG Secondary Antibody (yellow; Catalog # NL001) and counterstained with DAPI (blue). View our protocol for Fluorescent ICC Staining of Non-adherent Cells.
CCL19/MIP-3 beta in Mouse Dendritic Cells.
CCL19/MIP-3 beta was detected in immersion fixed mouse dendritic cells using Goat Anti-Mouse CCL19/MIP-3 beta Antigen Affinity-purified Polyclonal Antibody (Catalog # AF880) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Goat IgG Secondary Antibody (red; Catalog # NL001) and counterstained with DAPI (blue). View our protocol for Fluorescent ICC Staining of Non-adherent Cells.Applications for Mouse CCL19/MIP-3 beta Antibody
Application
Recommended Usage
Immunocytochemistry
5-15 µg/mL
Sample: Immersion fixed mouse splenocytes treated with PHA and immersion fixed mouse dendritic cells
Sample: Immersion fixed mouse splenocytes treated with PHA and immersion fixed mouse dendritic cells
Western Blot
0.1 µg/mL
Sample: Recombinant Mouse CCL19/MIP-3 beta (Catalog # 440-M3)
Sample: Recombinant Mouse CCL19/MIP-3 beta (Catalog # 440-M3)
Neutralization
Measured
by its ability to neutralize CCL19/MIP‑3 beta-induced chemotaxis in
the BaF3 mouse pro-B cell line transfected with human CCR7. The Neutralization
Dose (ND50) is typically 0.8-4 μg/mL in the
presence of 50 ng/mL Recombinant Mouse CCL19/MIP‑3 beta.
Reviewed Applications
Read 1 review rated 4 using AF880 in the following applications:
Formulation, Preparation, and Storage
Purification
Antigen Affinity-purified
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.
Shipping
Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Background: CCL19/MIP-3 beta
CCL19/MIP-3 beta, also known as ELC (EBI1-Ligand Chemokine), is a reported beta chemokine that binds specifically to the chemokine receptor CCR-7/EBI-1/BLR-2. Mouse (human) MIP-3 beta cDNA encodes a 108 (98) amino acid residue precursor protein with a predicted 25 (21) aa residue signal peptide that is cleaved to form the 83 (77) aa residue mature secreted protein. MIP-3 beta is distantly related to other beta chemokines (20-30% aa sequence identity). Mouse MIP-3 beta shares 83% aa sequence homology with human MIP-3 beta. MIP-3 beta has been shown to be constitutively expressed in various lymphoid tissues (including thymus, lymph nodes, appendix, and spleen) in dendritic cells within the T cell zone. The expression of MIP-3 beta is down-regulated by the anti-inflammatory cytokine IL-10. Recombinant MIP-3 beta has been shown to be chemotactic for T cells and B cells. The MIP-3 beta receptor (CCR7/EBI-1/BLR-2) is expressed in various lymphoid tissues and activated B and T lymphocytes. CCR7 is also strongly up-regulated in B cells infected with Epstein-Barr virus and T cells infected with herpes virus 6 or 7.
References
- Kim, C.H. et al. (1998) J. Immunol. 160:2418.
- Ngo, V.N. et al. (1998) J. Exp. Med. 188:181.
- Rossi, D.L. et al. (1997) J. Immunol. 158:1033.
- Yoshida, R. et al. (1997) J. Biol. Chem. 272:13803.
Alternate Names
ELC, MIP-3 beta, MIP3 beta
Gene Symbol
CCL19
UniProt
Additional CCL19/MIP-3 beta Products
Product Documents for Mouse CCL19/MIP-3 beta Antibody
Product Specific Notices for Mouse CCL19/MIP-3 beta Antibody
For research use only
